ABB 57310001-MP: Industrial Data Link for Smart Factory Connectivity

The ABB 57310001-MP Multibus Communication Board is a high-performance industrial network interface module engineered for seamless integration within ABB’s DSQC series distributed control systems. Designed to bridge field-level devices and supervisory control platforms, the 57310001-MP enables reliable, real-time data exchange across complex automation architectures — from signal acquisition at the sensor layer all the way to SCADA dashboards and MES platforms in the cloud or on-premise control room.

In modern smart factory environments, data continuity is mission-critical. The 57310001-MP serves as the communication backbone that connects PLCs, remote I/O modules, HMI panels, variable frequency drives, and intelligent sensors into a unified, transparent network. Whether deployed in process automation, discrete manufacturing, or hybrid production lines, this board eliminates communication dead zones and ensures every node in the automation chain is visible, controllable, and diagnostically accessible in real time.

Network Communication Table

Connected Automation Data Flow

The ABB 57310001-MP sits at the heart of the DSQC control node, orchestrating data flow between the system’s CPU module and its distributed I/O subsystems. In a typical deployment, field instruments — including pressure transmitters, flow meters, and temperature sensors — feed analog and digital signals into ABB DSQC I/O modules such as the DSQC 328A or DSQC 332 remote I/O boards. The 57310001-MP communication board then aggregates these signals over the Multibus backplane and routes them to the DSQC 500 series CPU for real-time processing.

Upstream, the processed data is forwarded via industrial Ethernet or PROFIBUS to SCADA platforms — such as ABB’s System 800xA or third-party supervisory systems — where operators monitor KPIs, configure alarm thresholds, and initiate remote control commands. HMI panels connected through the DSQC 503 operator interface module display live process variables, enabling floor-level operators to respond to events without latency.

For drive integration, the 57310001-MP supports communication with ABB ACS880 and ACS580 variable frequency drives via gateway modules, enabling speed reference commands and drive status feedback to flow bidirectionally across the network. Similarly, intelligent field devices — including smart valve positioners and motor protection relays — are integrated through protocol converters or fieldbus coupler modules such as the DSQC 352, ensuring that even legacy instruments participate in the digital data chain.

Edge gateway devices installed alongside the DSQC rack can further aggregate data from the 57310001-MP and push it to cloud-based analytics platforms or MES systems, enabling predictive maintenance algorithms to analyze vibration trends, thermal profiles, and cycle counts in real time. This end-to-end connectivity — from sensor to cloud — is what defines the smart factory data architecture that the ABB 57310001-MP enables.

Solving Data Isolation in Industrial Sites

One of the most persistent challenges in industrial automation is protocol fragmentation. Legacy systems often run on proprietary communication standards that cannot natively exchange data with modern Ethernet-based platforms. The ABB 57310001-MP addresses this directly by providing a standardized Multibus interface within the DSQC ecosystem, allowing older field devices and newer digital systems to coexist on the same communication backbone without costly infrastructure overhauls.

Data silos — where production data is trapped within individual machines or control islands — are eliminated when the 57310001-MP is properly integrated. By enabling the DSQC controller to aggregate I/O data from multiple field nodes and expose it to SCADA and MES layers, the board transforms isolated equipment into networked production assets. Plant managers gain full production line transparency: every motor, valve, sensor, and drive becomes a data source contributing to OEE calculations, energy monitoring, and quality traceability.

Remote monitoring and diagnostics are equally enhanced. Maintenance engineers can access live diagnostic data from the DSQC system — including communication error logs, module health status, and I/O fault registers — without physically visiting the control panel. This capability reduces mean time to repair (MTTR) and supports condition-based maintenance strategies that minimize unplanned downtime.

System scalability is another key advantage. As production capacity grows, additional DSQC I/O modules and communication boards can be added to the rack without redesigning the network architecture. The 57310001-MP’s Multibus interface supports modular expansion, making it a future-proof investment for facilities planning phased automation upgrades.

Industrial Connectivity FAQ

Q1: What communication protocols does the ABB 57310001-MP support?
The 57310001-MP is a Multibus communication board designed for ABB’s DSQC distributed control system architecture. It operates over the Multibus parallel backplane, enabling high-speed data exchange between the CPU module and I/O subsystems. For external network connectivity, the DSQC system supports PROFIBUS and Industrial Ethernet through dedicated gateway or communication modules within the same rack.

Q2: Is the 57310001-MP compatible with third-party SCADA and HMI systems?
Yes. When integrated within a DSQC controller, the 57310001-MP enables the system to communicate with third-party SCADA platforms — including Wonderware, Ignition, and Siemens WinCC — via standard OPC-DA/UA interfaces or PROFIBUS gateways. HMI panels from multiple vendors can also be connected through the appropriate communication interface modules in the DSQC rack.

Q3: How is network stability ensured in high-noise industrial environments?
The ABB DSQC series, including the 57310001-MP communication board, is designed to meet industrial EMC standards. The Multibus backplane architecture provides shielded, deterministic communication with defined cycle times, minimizing the impact of electrical noise from variable frequency drives, welding equipment, and high-current switching devices commonly found in factory environments.

Q4: What warranty and pre-shipment testing does the 57310001-MP include?
Every ABB 57310001-MP unit supplied by ZYPLC comes with a 12-month warranty and undergoes pre-shipment functional testing to verify communication integrity and module health. Units are shipped via DHL or FedEx Express with full tracking. RFQ responses are provided within 24 hours, and in-stock units are typically dispatched within 1–3 business days.
