ABB DRM570024LT-AU Industrial Network Interface for DRM Series Systems

ABB DRM570024LT-AU Industrial Network Interface for DRM Series Systems: Bridging Field Devices and Smart Factory Data Links

In modern industrial environments, seamless data flow between field-level devices and upper-level control systems is no longer optional — it is the foundation of operational efficiency. The ABB DRM570024LT-AU (Part No. 3ABD00036448), a 4CO 24V DC relay module from ABB’s proven DRM Series, serves as a critical switching and signal interface node within distributed automation architectures. Designed for demanding industrial applications, this relay module enables reliable protocol-level signal conversion, discrete I/O bridging, and stable network communication between PLCs, remote I/O systems, HMIs, SCADA platforms, and field instrumentation — all within a compact, DIN-rail-mountable form factor.

Whether deployed in a new smart factory build-out or integrated into an existing brownfield automation network, the DRM570024LT-AU delivers the switching reliability and signal integrity that industrial connectivity demands. Its 4-changeover (4CO) contact configuration supports flexible wiring topologies, while the 24V DC coil voltage aligns with standard PLC output modules and industrial power distribution systems, minimizing engineering overhead during commissioning.

Network Communication Table

Connected Automation Data Flow

The DRM570024LT-AU occupies a pivotal position in the industrial data chain. In a typical smart factory deployment, field sensors — such as ABB’s 2600T Series pressure transmitters or TSP temperature sensors — generate analog and digital signals that are first captured by remote I/O modules. These signals are then routed through the DRM570024LT-AU relay interface, which provides galvanic isolation and clean switching to the PLC layer. ABB’s AC500 PLC series, widely deployed in process and discrete manufacturing, relies on relay modules like the DRM570024LT-AU to interface its digital output channels with high-current field actuators, motor starters, and solenoid valves.

Within the network communication layer, the relay module works in concert with ABB CP600 HMI panels, which visualize real-time switching states and alarm conditions. SCADA systems — such as those built on ABB’s System 800xA or third-party platforms like Wonderware and Ignition — poll the PLC for relay status data via Modbus TCP/IP or PROFIBUS DP gateways, enabling operators to monitor contact states, cycle counts, and fault conditions from a centralized control room.

For distributed architectures, the DRM570024LT-AU integrates naturally with ABB CI854 PROFIBUS communication interface modules and CM589 PROFINET interface modules, allowing relay status data to be transmitted across industrial Ethernet backbones to edge gateways and cloud-based MES platforms. In drive-intensive applications, the relay module provides interlock and enable signals to ABB ACS880 variable frequency drives, ensuring safe sequencing during motor start/stop cycles. The result is a fully transparent data flow — from sensor signal acquisition, through relay switching, PLC processing, network transmission, and up to SCADA visualization and remote diagnostics.

Solving Data Isolation in Industrial Sites

One of the most persistent challenges in industrial automation is the fragmentation of control systems — legacy PLCs running proprietary protocols, field devices with incompatible signal types, and SCADA systems unable to access real-time switching data from relay-level components. The ABB DRM570024LT-AU directly addresses these pain points.

Protocol Unification: By serving as a 24V DC discrete interface, the DRM570024LT-AU bridges the gap between modern PLC digital output modules and legacy field devices that require dry-contact switching. This eliminates the need for custom signal conditioning hardware and reduces wiring complexity.

Eliminating Data Silos: When integrated with ABB’s S900 remote I/O system or third-party Modbus RTU gateways, relay contact states can be mapped as digital input registers, making previously invisible switching events fully visible to SCADA and MES layers. Production line transparency improves dramatically when every relay actuation is logged and time-stamped.

Remote Monitoring and Diagnostics: Through PLC-level integration, the DRM570024LT-AU’s contact states can be monitored remotely via industrial VPN gateways or cellular RTUs, enabling maintenance teams to diagnose relay faults, count contact cycles, and predict replacement intervals without on-site visits — a key enabler of predictive maintenance strategies.

System Scalability: The DRM Series modular design allows engineers to expand relay capacity incrementally. Additional DRM570024LT-AU modules can be added to existing DIN rail assemblies without rewiring the control cabinet, supporting phased factory expansion and production line reconfiguration with minimal downtime.

Pre-Shipment Testing and Quality Assurance: Every DRM570024LT-AU unit supplied by ZYPLC undergoes functional verification prior to dispatch, including coil energization testing and contact continuity checks. Combined with a 12-month warranty, this ensures that your automation project proceeds without component-related delays.

Industrial Connectivity FAQ

Q1: What is the communication latency of the DRM570024LT-AU in a PLC-controlled relay network?
The DRM570024LT-AU operates as a discrete switching device; its relay operate time is typically within 10ms, which is well within the scan cycle requirements of most PLC systems including the ABB AC500 series. When relay status is polled via Modbus TCP/IP or PROFIBUS DP, end-to-end latency from PLC output command to SCADA status update is typically under 100ms in a well-configured network.

Q2: Is the DRM570024LT-AU compatible with non-ABB PLC systems and third-party SCADA platforms?
Yes. The 24V DC coil voltage is a universal standard in industrial automation, making the DRM570024LT-AU compatible with Siemens S7, Mitsubishi MELSEC, Schneider Modicon, and other major PLC platforms. Contact status can be integrated into any SCADA system capable of reading digital inputs from the connected PLC, including Ignition, Wonderware, and WinCC.

Q3: How does the DRM570024LT-AU contribute to network stability in high-cycle industrial applications?
The 4CO contact design provides redundant switching paths, and the module’s coil suppression circuitry minimizes electromagnetic interference (EMI) on the 24V DC control bus — a critical factor in maintaining stable Modbus RTU and PROFIBUS communications in electrically noisy environments such as motor control centers and variable frequency drive panels.

Q4: What warranty and after-sales support does ZYPLC provide for the DRM570024LT-AU?
ZYPLC provides a 12-month warranty on all DRM570024LT-AU units. Each module is functionally tested before shipment. In the event of a warranty claim, ZYPLC’s technical team provides remote diagnostic support and expedited replacement to minimize production downtime. Stock is maintained for immediate dispatch to support urgent project timelines.
