ABB SNAT 7070 SNAZ 7070-J Industrial Network Interface for ACS800 Systems

ABB SNAT 7070 SNAZ 7070-J: Industrial Data Link for ACS800 Drive Networks

The ABB SNAT 7070 / SNAZ 7070-J is a high-performance fiber optic communication board engineered for seamless integration within ABB ACS800 variable speed drive systems. Designed to operate on ABB’s proprietary DDCS (Distributed Drive Communication System) fiber optic protocol, this board serves as the critical data link between field-level drive hardware and upper-level control architectures — including PLC controllers, SCADA platforms, HMI terminals, and remote I/O systems. In smart factory environments where real-time data integrity and network stability are non-negotiable, the SNAT 7070 / SNAZ 7070-J delivers the communication backbone that keeps production lines transparent, responsive, and continuously monitored.

Industrial connectivity begins at the signal level. When sensors on a motor-driven conveyor, pump, or compressor generate process data — speed feedback, torque values, fault codes, thermal readings — that data must travel reliably from the ACS800 drive through a structured communication chain to reach the control room. The SNAT 7070 / SNAZ 7070-J board handles this upstream data flow with precision, using fiber optic transmission to eliminate electromagnetic interference common in high-voltage drive environments. This makes it especially valuable in applications where copper-based communication would be susceptible to noise from adjacent variable frequency drives, servo amplifiers, or high-current bus bars.

Network Communication Table

Connected Automation Data Flow

In a typical ACS800-based drive system, the SNAT 7070 / SNAZ 7070-J board is installed in the drive’s option slot, establishing a DDCS fiber optic ring that connects multiple drives in a master-follower configuration. Consider a multi-drive paper mill or steel rolling line: the ABB AC500 PLC acts as the DDCS master, issuing speed references and torque commands to each ACS800-01 or ACS800-04 drive unit via the fiber ring. The SNAT 7070 board on each follower drive receives these commands and returns real-time status data — actual speed, output current, DC bus voltage, and active fault codes — back to the master controller within each communication cycle.

This data flow extends upward through the automation hierarchy. An RMIO-01C control board within the ACS800 processes the drive’s internal logic, while the SNAT 7070 / SNAZ 7070-J handles the external communication layer. Where fieldbus connectivity to a PROFIBUS or EtherNet/IP network is required, an RDNA-01 DeviceNet adapter or RPBA-01 PROFIBUS adapter can be added alongside the SNAT 7070, enabling the ACS800 to participate in broader plant-wide networks. This layered approach allows a single ACS800 drive to simultaneously communicate on the DDCS fiber ring for drive-to-drive coordination and on a fieldbus network for SCADA integration.

At the HMI level, operators using ABB’s DriveWindow or Panel Builder-based terminals can monitor live drive parameters sourced through the SNAT 7070 communication path. Alarm conditions — overcurrent trips, earth faults, communication timeouts — are transmitted in real time to the SCADA system, enabling immediate operator response without requiring physical inspection of the drive cabinet. In remote installations such as offshore platforms, water treatment facilities, or mining operations, this remote diagnostic capability is essential for reducing unplanned downtime.

The SNAT 7070 / SNAZ 7070-J also plays a role in coordinating with adjacent automation components. In a coordinated drive system, an RINT-5611C interface board may handle the internal DDCS communication within a multi-drive cabinet, while the SNAT 7070 manages the external ring connection to the PLC. Similarly, in ACS880 migration projects where legacy ACS800 drives remain in service alongside newer hardware, the SNAT 7070 ensures backward compatibility within the DDCS network, protecting the existing communication infrastructure investment. For applications requiring edge-level data aggregation, an industrial edge gateway can collect DDCS data via a protocol converter and forward it to cloud-based MES or ERP platforms, completing the data chain from field device to enterprise system.

Solving Data Isolation in Industrial Sites

One of the most persistent challenges in industrial automation is data isolation — the condition where drive systems, sensors, and controllers operate in silos, unable to share process data across the plant network. The ABB SNAT 7070 / SNAZ 7070-J directly addresses this problem by providing a standardized, high-speed fiber optic communication path that integrates ACS800 drives into the broader automation architecture.

In facilities where multiple drive generations coexist — ACS600, ACS800, and ACS880 units operating on the same production line — protocol inconsistency creates gaps in data visibility. The SNAT 7070 board, combined with appropriate gateway modules, bridges these gaps by enabling DDCS-native drives to exchange data with Modbus RTU, PROFIBUS DP, or EtherNet/IP networks. This protocol translation capability is fundamental to achieving production line transparency, where every drive’s operating state is visible to the SCADA system without manual data collection.

Remote monitoring is another area where the SNAT 7070 / SNAZ 7070-J delivers measurable value. In geographically distributed installations — pumping stations, wind farms, or multi-site manufacturing — the ability to remotely diagnose drive faults, read parameter sets, and verify communication health reduces the need for on-site service visits. Maintenance teams can identify a communication fault on a specific ACS800-07 drive, review its fault history via DriveWindow, and dispatch a technician with the correct replacement board — all before the drive has been physically inspected.

System expansion is simplified by the DDCS ring topology supported by the SNAT 7070. Adding a new ACS800 drive to an existing fiber ring requires only a fiber optic connection and address configuration — no rewiring of the control panel or reconfiguration of the PLC communication stack. This scalability makes the SNAT 7070 / SNAZ 7070-J a long-term investment for facilities planning phased automation upgrades.

Every SNAT 7070 / SNAZ 7070-J unit supplied by ZYPLC undergoes functional testing prior to shipment, verifying communication integrity, fiber port operation, and board-level diagnostics. Units are backed by a 12-month warranty and are available from stock for immediate dispatch to global destinations.

Industrial Connectivity FAQ

Q: What communication protocol does the ABB SNAT 7070 / SNAZ 7070-J use?
A: The SNAT 7070 / SNAZ 7070-J operates on ABB’s DDCS (Distributed Drive Communication System) fiber optic protocol. This is a proprietary high-speed protocol used for drive-to-drive and drive-to-controller communication within ABB ACS800 series systems. It is not directly compatible with standard fieldbus protocols such as PROFIBUS or EtherNet/IP without an additional gateway or adapter module.

Q: Is the SNAT 7070 compatible with ACS880 or other ABB drive series?
A: The SNAT 7070 / SNAZ 7070-J is specifically designed for the ACS800 series, including ACS800-01, ACS800-04, ACS800-07, ACS800-11, and ACS800-17 variants. While the DDCS protocol is also used in some ACSM1 and earlier ACS600 configurations, compatibility with ACS880 drives should be verified against the specific hardware revision and option slot configuration before installation.

Q: How does the SNAT 7070 support network stability in high-interference environments?
A: Fiber optic transmission is inherently immune to electromagnetic interference (EMI), making the SNAT 7070 / SNAZ 7070-J well-suited for installation in drive cabinets where high-frequency switching noise from IGBTs and PWM signals would degrade copper-based communication. The fiber optic medium ensures signal integrity across the DDCS ring regardless of the electrical environment.

Q: What testing and warranty coverage is provided with ZYPLC-supplied SNAT 7070 units?
A: All SNAT 7070 / SNAZ 7070-J boards supplied by ZYPLC are functionally tested prior to shipment, including verification of fiber optic port operation and DDCS communication integrity. Each unit is covered by a 12-month warranty against manufacturing defects and functional failure. Units are available from stock and can be dispatched globally with standard lead times.
