Allen-Bradley 1336-QOUT-SP13A Drive Output Module: Control System and system integration for 1336 Series
The Allen-Bradley 1336-QOUT-SP13A is a dedicated drive output module engineered for seamless integration within the 1336 Series variable frequency drive (VFD) platform. Rather than functioning as a standalone component, this module occupies a critical position within the broader control system architecture — bridging the power conversion stage and the motor load interface while maintaining signal integrity, output conditioning, and system-level coordination across multiple automation layers. For engineers designing or maintaining industrial drive systems, the 1336-QOUT-SP13A represents a precision-matched solution that upholds the performance standards of the complete 1336 Series ecosystem.
In modern layered automation environments, every component must be evaluated not only by its individual specification but by its contribution to system coherence. The 1336-QOUT-SP13A fulfills this requirement by providing conditioned output signal paths that reduce electrical noise, protect downstream motor windings, and ensure compatibility with the drive’s internal control logic. Its design reflects Allen-Bradley’s commitment to modular, scalable drive architecture — enabling engineers to configure, expand, and maintain systems without compromising uptime or performance.
Product Specification Table
| Parameter |
Specification |
| Part Number / SKU |
1336-QOUT-SP13A |
| Brand |
Allen-Bradley (Rockwell Automation) |
| Series |
1336 Series (1336 PLUS / 1336 PLUS II / 1336 IMPACT) |
| System Role |
Drive Output Module — Output Signal Conditioning & Motor Interface |
| Product Type |
Drive Output Module / VFD Accessory |
| Electrical Compatibility |
Compatible with 1336 Series VFD output stages; supports three-phase motor output conditioning |
| Communication Capability |
Integrated within 1336 Series drive backplane; compatible with drive-level communication adapters including 1336-GM1 (DeviceNet), 1336-GM6 (ControlNet), and 1336-GM-DF1 (DH+/RS-232) |
| Installation Environment |
Panel-mount within standard 1336 Series drive enclosure; suitable for industrial environments per NEMA/IEC standards |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) — consistent with 1336 Series platform ratings |
| Mounting |
Direct drive module slot installation; no external wiring harness required |
| Origin |
United States (Allen-Bradley / Rockwell Automation) |
| Warranty |
warranty terms confirmed during quotation — covers manufacturing defects and functional failure under normal operating conditions |
| system integration |
Supports system integration within 1336 Series drive architecture; compatible with upstream PLC control and downstream motor load systems |
System Compatibility Notes
The 1336-QOUT-SP13A does not operate in isolation — it is one node in a carefully coordinated control system that spans multiple functional layers. Understanding its role requires examining how it interacts with adjacent components across the control hierarchy.
At the control layer, the 1336-QOUT-SP13A receives operational commands from Allen-Bradley PLC platforms such as the ControlLogix 1756-L71 or CompactLogix 1769-L33ER, which manage drive speed references, torque limits, and fault response logic via the drive’s communication adapter. The PLC’s output instructions are translated into drive parameters that govern how the output module conditions the motor-facing signals.
At the drive and power layer, the module works in direct coordination with the 1336 Series drive’s internal power stage. It is designed to complement components such as the 1336-QOUT-SP14A (a related output module variant) and the 1336-BRF-SP3A brake resistor assembly, ensuring that regenerative energy and output transients are managed without stressing the motor insulation system. The 1336-MOD-HA2 and similar drive option modules may also be present in the same drive chassis, sharing the backplane and requiring coordinated parameter configuration.
At the I/O and signal layer, the 1336-QOUT-SP13A interfaces with the drive’s analog and digital I/O structure. In systems using the 1771 I/O platform or 1734 POINT I/O modules for remote process feedback, the output module ensures that the drive’s response to field signals remains stable and within the defined control envelope. Proper grounding and shielding practices — consistent with Allen-Bradley’s drive installation guidelines — are essential to maintaining signal fidelity at this layer.
At the network and communication layer, the 1336 Series drive communicates with the broader automation network via adapters such as the 1336-GM1 DeviceNet adapter or 1336-GM6 ControlNet adapter. These communication modules allow the PLC to monitor drive status, adjust speed references in real time, and log fault data — all of which depend on the output module maintaining stable, predictable motor control. In redundant network architectures, dual-port ControlNet adapters may be employed to ensure uninterrupted communication even during network segment failures.
At the HMI layer, operator interfaces such as the PanelView Plus 6 (2711P series) provide real-time visualization of drive status, output frequency, motor current, and fault codes. The data displayed on the HMI is only as reliable as the underlying drive hardware — making the integrity of the 1336-QOUT-SP13A directly relevant to operator situational awareness and process transparency.
At the execution layer, the conditioned output signals from the 1336-QOUT-SP13A drive induction motors, servo-assisted conveyors, pump systems, and fan arrays. In applications where motor protection relays such as the Allen-Bradley 193-EC1 E3 Plus are installed downstream, the output module’s signal quality directly influences the accuracy of current monitoring and thermal protection functions.
Industrial Application Notes
The 1336-QOUT-SP13A finds application across a wide range of industrial sectors where the 1336 Series VFD platform has been deployed as a standard drive solution.
In manufacturing and assembly lines, the module supports precise motor speed control for conveyor systems, robotic transfer units, and packaging machinery. Its ability to condition output signals reduces motor heating and extends winding life — a critical factor in high-duty-cycle production environments where unplanned downtime carries significant cost.
In power generation and electrical utilities, 1336 Series drives equipped with the 1336-QOUT-SP13A are used to control auxiliary motor loads such as cooling fans, fuel feed pumps, and excitation system auxiliaries. The module’s compatibility with the drive’s fault detection and protection logic ensures that abnormal output conditions are identified and isolated before they propagate to connected equipment.
In petrochemical and refinery applications, where process continuity is paramount, the 1336-QOUT-SP13A supports drives controlling compressor motors, agitator drives, and transfer pump systems. Its integration within the 1336 Series architecture allows maintenance teams to replace or reconfigure the output module without requiring full drive replacement — reducing both downtime and spare parts inventory costs.
In water and wastewater treatment facilities, variable speed pump control is a core operational requirement. The 1336-QOUT-SP13A enables smooth motor acceleration and deceleration profiles that reduce water hammer effects and extend pump mechanical life. Combined with the drive’s PID control capability and PLC-level supervisory logic, it supports fully automated flow management across treatment stages.
In mining and mineral processing, where drives operate in harsh environments with high ambient temperatures and significant electrical noise, the output module’s signal conditioning function is especially valuable. It helps maintain motor control stability even when the electrical environment is compromised by nearby high-power equipment or long cable runs to remote motor loads.
In metallurgical and steel mill applications, the 1336-QOUT-SP13A supports drives controlling rolling mill motors, cooling bed conveyors, and ladle transfer systems. The module’s compatibility with the 1336 Series drive’s torque control modes makes it suitable for tension-regulated applications where precise output control is essential to product quality.
Product Compatibility FAQ
Q1: Is the 1336-QOUT-SP13A compatible with all variants of the 1336 Series drive platform, and what should engineers verify before installation?
The 1336-QOUT-SP13A is designed for use within the 1336 Series VFD family, which includes the 1336 PLUS, 1336 PLUS II, and 1336 IMPACT drive variants. Before installation, engineers should verify the drive’s firmware revision and catalog number to confirm output module slot compatibility. The drive’s user manual and Allen-Bradley product compatibility matrix should be consulted to ensure that the specific drive revision supports the SP13A output module variant. In systems where the drive communicates via a 1336-GM1 or 1336-GM6 adapter, the communication adapter’s parameter configuration should also be reviewed to confirm that output module status is correctly mapped to the network data table.
Q2: How does the 1336-QOUT-SP13A contribute to system redundancy and long-term maintenance efficiency in critical process applications?
In critical process applications, maintaining a spare 1336-QOUT-SP13A in the site’s spare parts inventory is a recognized best practice for minimizing mean time to repair (MTTR). Because the module is a field-replaceable unit within the 1336 Series drive chassis, a trained technician can swap the output module without replacing the entire drive — preserving the drive’s parameter configuration and reducing the time required to return the system to service. For facilities operating multiple 1336 Series drives, standardizing on a common output module variant simplifies spare parts management and reduces the total inventory investment required to support the installed base. The warranty terms confirmed during quotation provided with each 1336-QOUT-SP13A sourced from ZYPLC covers manufacturing defects and functional failure under normal operating conditions, providing additional assurance during the initial post-installation period.
Q3: What commissioning steps are recommended when integrating the 1336-QOUT-SP13A into an existing 1336 Series drive system, and how should the warranty terms confirmed during quotation be managed?
When integrating the 1336-QOUT-SP13A into an existing drive system, the recommended commissioning sequence begins with a full drive power-down and lockout/tagout (LOTO) procedure before module installation. After physical installation, the drive should be powered up in a no-load condition to verify that the output module is recognized by the drive’s self-diagnostic routine. Output voltage and frequency measurements at the drive terminals should be compared against the drive’s programmed output parameters to confirm correct module operation. Any fault codes generated during initial power-up should be documented and resolved before connecting the motor load. The warranty terms confirmed during quotation period begins from the date of purchase; customers are advised to retain the purchase documentation and record the installation date to facilitate any warranty claims. ZYPLC’s technical support team is available to assist with commissioning questions and warranty administration throughout the warranty period.
