Allen-Bradley 1336F-MCB-SP1C FORCE Series Drive Control PC Board

Allen-Bradley 1336F-MCB-SP1C: Industrial Data Link for Smart Factory Connectivity

The Allen-Bradley 1336F-MCB-SP1C is a FORCE Series drive control PC board engineered for seamless integration within modern industrial communication architectures. Designed to serve as the intelligence layer inside Allen-Bradley FORCE Series AC drives, this board enables real-time data exchange between field-level devices and upper-level control and monitoring systems. In smart factory environments where uptime, data transparency, and protocol interoperability are non-negotiable, the 1336F-MCB-SP1C delivers the connectivity backbone that keeps production lines running and data flowing without interruption.

From the moment a signal is captured at a field sensor or encoder, the 1336F-MCB-SP1C begins its role in the industrial data chain. It processes drive-level feedback — including speed reference, torque output, fault status, and thermal conditions — and makes this data available to upstream controllers and SCADA platforms. Whether the plant runs on a DeviceNet backbone, a Remote I/O (RIO) network, or a DH+ communication link, this board is built to participate in the data flow that defines connected automation.

Network Communication Table

Connected Automation Data Flow

In a typical smart factory deployment, the 1336F-MCB-SP1C sits at the heart of the drive control loop, bridging the gap between motor-level actuation and plant-wide data visibility. Consider a production line where a PLC-5 controller — or a more modern ControlLogix L7x series processor — issues speed commands to a FORCE Series drive. The 1336F-MCB-SP1C receives these commands via the Remote I/O network, translates them into precise PWM output signals, and simultaneously feeds back real-time motor status data to the controller.

This feedback loop is critical for SCADA platforms such as Rockwell’s FactoryTalk View or third-party HMI systems connected via an RSLinx gateway. Operators monitoring a FactoryTalk SE supervisory screen can observe drive speed, current draw, and fault codes in real time — all made possible by the data pipeline that the 1336F-MCB-SP1C anchors. When paired with a 1336-GM1 or 1336-BDB-SP2 interface board, the system’s communication reach extends further, enabling multi-drive coordination across a single RIO drop.

At the field level, proximity sensors, encoders, and process transmitters feed analog and digital signals into remote I/O modules such as the 1771-OFE or 1771-IFE series. These signals are aggregated and passed up the network to the PLC, which then issues corrective commands back down to the FORCE Series drive through the 1336F-MCB-SP1C. This closed-loop architecture ensures that process deviations — whether a conveyor speed drift or a pump pressure anomaly — are detected and corrected within milliseconds.

For facilities integrating variable frequency drives (VFDs) with energy management systems, the 1336F-MCB-SP1C also supports integration with PowerMonitor 3000 or similar Rockwell energy metering devices via the DH+ link, enabling kWh tracking and demand response at the drive level. Edge gateways such as the Moxa MGate series or Rockwell’s 1783-NATR NAT router can further bridge this data to cloud-based MES or ERP platforms, completing the IIoT data chain from motor shaft to enterprise dashboard.

Solving Data Isolation in Industrial Sites

One of the most persistent challenges in legacy industrial environments is data isolation — where drives, PLCs, and sensors operate on incompatible protocols, making plant-wide visibility impossible without costly middleware. The 1336F-MCB-SP1C directly addresses this by providing a standardized communication interface within the Allen-Bradley FORCE Series ecosystem, ensuring that drive data is not siloed at the device level but is instead available to any authorized system on the network.

For plants transitioning from standalone drive operation to fully networked automation, replacing a failed or obsolete control board with the 1336F-MCB-SP1C restores not just drive functionality but the entire communication link between the drive and the control system. This is particularly critical in facilities where a single drive failure can halt an entire production segment — a bottling line, a conveyor system, or a compressor station — due to the loss of network communication rather than mechanical failure alone.

Protocol unification is another key benefit. Where older installations may rely on DH+ for PLC-to-drive communication while newer expansions use EtherNet/IP, the 1336F-MCB-SP1C can serve as the legacy anchor point, with protocol conversion handled upstream by a 1761-NET-AIC or a ControlLogix EtherNet/IP bridge module. This hybrid architecture allows plants to modernize incrementally without scrapping existing drive infrastructure, protecting capital investment while expanding network transparency.

Remote diagnostics capabilities enabled by the 1336F-MCB-SP1C allow maintenance engineers to interrogate drive fault histories, parameter settings, and runtime statistics from a central control room or even a remote location via VPN-connected SCADA terminals. This reduces mean time to repair (MTTR) by enabling pre-dispatch diagnosis — technicians arrive on-site already knowing which component failed and what replacement is needed, minimizing production downtime.

Industrial Connectivity FAQ

Q1: What communication protocols does the 1336F-MCB-SP1C support, and is it compatible with modern EtherNet/IP networks?
The 1336F-MCB-SP1C natively supports Allen-Bradley Remote I/O (RIO) and DH+ communication protocols, which are standard in legacy PLC-5 and SLC 500 control architectures. For integration with modern EtherNet/IP or DeviceNet networks, a protocol gateway or bridge module — such as the 1761-NET-AIC or a third-party Anybus gateway — is required. This allows the board to participate in contemporary IIoT and SCADA architectures without requiring a full drive replacement.

Q2: How does the 1336F-MCB-SP1C ensure network stability in high-noise industrial environments?
The board is designed to Allen-Bradley’s industrial-grade specifications, incorporating noise immunity measures appropriate for environments with high electromagnetic interference (EMI) from motors, welding equipment, and power switching devices. Proper grounding of the drive cabinet, use of shielded RIO cables, and adherence to Rockwell Automation’s wiring guidelines are recommended to maintain network stability and minimize communication errors on the RIO or DH+ link.

Q3: Can the 1336F-MCB-SP1C be used for system expansion — adding more drives to an existing RIO network?
Yes. The Remote I/O architecture supported by the 1336F-MCB-SP1C allows multiple drives to be addressed on a single RIO network segment, subject to the node limits of the connected PLC scanner module. Each FORCE Series drive with a properly configured 1336F-MCB-SP1C can be assigned a unique RIO address, enabling centralized control and monitoring of multiple drives from a single PLC-5 or SLC 500 controller without additional hardware beyond standard RIO cabling.

Q4: What quality assurance and warranty coverage is provided with the 1336F-MCB-SP1C?
Every 1336F-MCB-SP1C unit supplied by ZYPLC undergoes pre-shipment functional testing to verify communication interface integrity, board-level power regulation, and control signal output. Units are covered by a 12-month warranty against manufacturing defects and functional failures. In the event of a warranty claim, ZYPLC provides rapid replacement or repair support to minimize production impact. Stock is maintained for immediate dispatch via DHL or FedEx international express services.
