Allen-Bradley 1606-XLE240EE Industrial Power Supply for 1606-XLE Systems

Allen-Bradley 1606-XLE240EE: Industrial Data Link Power for Smart Factory Systems

In modern smart manufacturing environments, stable and reliable DC power is the invisible backbone of every industrial data link. The Allen-Bradley 1606-XLE240EE is a 240W DIN Rail-mounted power supply from Rockwell Automation’s proven 1606-XLE Series, engineered to deliver consistent 24VDC output across the full spectrum of industrial automation architectures — from field-level sensor networks to enterprise-level SCADA platforms.

As industrial sites evolve toward IIoT-driven connectivity, the power infrastructure must match the demands of real-time data transmission, protocol conversion, and continuous network uptime. The 1606-XLE240EE is purpose-built for exactly these environments, providing the clean, regulated power that keeps communication modules, remote I/O racks, HMI panels, and edge gateways operating without interruption.

Network Communication Table

Connected Automation Data Flow

The 1606-XLE240EE sits at the heart of the industrial power distribution layer, energizing the devices that form the backbone of your connected factory. In a typical ControlLogix or CompactLogix PLC architecture, the power supply feeds the backplane and communication modules — such as the 1756-EN2T EtherNet/IP module or the 1756-DNB DeviceNet Bridge — enabling high-speed data exchange between the controller and field devices.

Downstream, the 1606-XLE240EE powers 1734 POINT I/O and 1769 Compact I/O remote racks distributed across the production floor. These I/O nodes collect real-time signals from proximity sensors, pressure transmitters, and temperature probes, forwarding structured data packets upstream through EtherNet/IP or DeviceNet to the ControlLogix processor. The power supply’s low ripple and noise characteristics are critical here — any voltage instability can corrupt fieldbus communication frames and trigger false alarms in the SCADA layer.

At the HMI level, PanelView Plus 7 terminals draw their 24VDC supply from the same distribution rail, rendering live process data visualized from the FactoryTalk View SE SCADA platform. The 1606-XLE240EE’s parallel operation capability allows two units to share load, ensuring redundant power delivery to mission-critical HMI and communication nodes without a single point of failure.

For sites integrating legacy serial devices — such as older Modbus RTU sensors or RS-485 instruments — the power supply energizes 1761-NET-AIC Advanced Interface Converters and third-party Modbus TCP/RTU gateways, bridging the protocol gap between legacy field instruments and modern EtherNet/IP networks. This protocol conversion layer is essential for achieving full plant-floor data transparency without replacing existing field hardware.

In variable frequency drive (VFD) panels, the 1606-XLE240EE powers the control circuits of PowerFlex 525 and PowerFlex 755 drives, as well as their embedded EtherNet/IP adapters. Drive status, speed references, fault codes, and energy consumption data flow continuously from the drive’s communication port to the ControlLogix controller and onward to the FactoryTalk Historian for long-term performance trending and predictive maintenance analysis.

Edge computing nodes — including Cisco IE-4000 Industrial Ethernet Switches and Rockwell’s Stratix 5700 managed switches — rely on stable 24VDC input to maintain the network fabric connecting all automation layers. The 1606-XLE240EE’s wide-range AC input (85–264VAC) makes it equally suitable for global deployments, from North American 120VAC panels to European 230VAC distribution boards, without any hardware modification.

Solving Data Isolation in Industrial Sites

One of the most persistent challenges in industrial automation is data isolation — the condition where field devices, controllers, and enterprise systems operate in disconnected silos, preventing real-time visibility and coordinated control. The 1606-XLE240EE directly addresses this challenge by providing the stable power foundation that enables protocol-bridging gateways and multi-network communication modules to operate continuously and reliably.

When a plant runs mixed protocols — EtherNet/IP on the controller level, DeviceNet on the sensor bus, and Modbus TCP toward the SCADA server — the communication gateways performing real-time protocol translation must never lose power. A momentary voltage dip can cause a gateway to reboot, severing the data link between the field and the control room for seconds or minutes. The 1606-XLE240EE’s >91% efficiency and active power factor correction minimize heat generation and voltage fluctuation, keeping gateways and communication modules online even during input voltage transients.

For remote monitoring applications, the power supply enables always-on connectivity for cellular or fiber-based remote I/O nodes deployed in substations, water treatment facilities, and oil & gas wellheads. Operators at a central SCADA workstation can monitor real-time process values, acknowledge alarms, and issue control commands to remote PLCs — all dependent on the uninterrupted 24VDC supply that the 1606-XLE240EE delivers.

Production line transparency — the ability to see OEE metrics, cycle times, reject rates, and energy consumption in real time — requires every sensor, actuator, and controller to be continuously powered and communicating. The 1606-XLE240EE supports this transparency by powering the distributed I/O and communication infrastructure that feeds data to MES and ERP systems, enabling data-driven decisions at every level of the manufacturing enterprise.

System expansion is equally straightforward: the 1606-XLE240EE’s parallel operation and redundancy features allow engineers to scale power capacity incrementally as new I/O nodes, communication modules, or edge devices are added to the network — without redesigning the power distribution architecture.

Industrial Connectivity FAQ

Q1: Does the 1606-XLE240EE support redundant power configurations for critical communication nodes?
Yes. The 1606-XLE240EE supports parallel operation with diode ORing modules, enabling N+1 redundancy for powering critical communication gateways, remote I/O racks, and HMI panels. This ensures continuous data flow even if one power supply unit fails.

Q2: Is the 1606-XLE240EE compatible with EtherNet/IP and DeviceNet network architectures?
The 1606-XLE240EE provides the 24VDC power required by EtherNet/IP communication modules (e.g., 1756-EN2T), DeviceNet scanners (e.g., 1756-DNB), and Modbus TCP gateways. It does not itself participate in the network protocol but is the essential power source for all these communication devices.

Q3: What is the communication latency impact of power supply instability on industrial networks?
Voltage ripple and transients from low-quality power supplies can introduce CRC errors and retransmission delays in fieldbus communications, effectively increasing network latency. The 1606-XLE240EE’s low output ripple (<50mV peak-to-peak) and fast transient response ensure that communication modules receive clean power, maintaining deterministic network timing required by EtherNet/IP and ControlNet protocols.

Q4: What warranty and pre-shipment testing does the 1606-XLE240EE include?
Every 1606-XLE240EE unit supplied by ZYPLC is covered by a 12-month warranty and undergoes full functional testing — including output voltage verification, load regulation testing, and protection circuit validation — before shipment. This ensures that units arrive ready for immediate installation in your automation panel.
