Allen-Bradley 1606-XLS240E Industrial Network Interface for XLS Series Systems

Allen-Bradley 1606-XLS240E: Industrial Data Link Power Infrastructure for Smart Factory Networks

The Allen-Bradley 1606-XLS240E is a 240W, 24VDC DIN Rail-mounted industrial power supply engineered for the demanding requirements of modern smart factory environments. As a core component of the XLS Series power platform, the 1606-XLS240E delivers stable, regulated DC power to the full spectrum of industrial automation devices — from field-level sensors and actuators to PLC controllers, remote I/O modules, HMI panels, SCADA gateways, and edge computing nodes. In an era where uninterrupted data flow is as critical as uninterrupted power, the 1606-XLS240E serves as the foundational energy backbone that keeps every node in your industrial network online and communicating.

Industrial connectivity architectures depend on consistent, clean power at every layer of the automation pyramid. Signal noise, voltage sag, or power interruption at any point in the network can cascade into communication failures across EtherNet/IP, PROFINET, Modbus TCP, DeviceNet, and ControlNet segments. The 1606-XLS240E addresses this challenge with its wide-range AC input (85–264VAC), active power factor correction, and output voltage fine-tuning capability — ensuring that every connected device, from a compact 1769-L30ER CompactLogix PLC to a distributed 1734-AENT POINT I/O EtherNet/IP adapter, receives the precise voltage it requires for stable protocol communication.

Network Communication Table

Connected Automation Data Flow

In a typical smart factory deployment, the 1606-XLS240E sits at the heart of the control panel, powering the entire communication chain from field device to enterprise system. Consider a production line where a 1769-L33ER CompactLogix 5370 PLC orchestrates motion, I/O, and process control via EtherNet/IP. The PLC communicates upstream to a FactoryTalk View SE SCADA server and downstream to a 1734-AENT POINT I/O EtherNet/IP Adapter that aggregates signals from proximity sensors, photoelectric detectors, and pneumatic valve solenoids. Every one of these nodes — the PLC, the I/O adapter, the managed industrial Ethernet switch, and the HMI terminal — draws its operating power from a stable 24VDC bus supplied by the 1606-XLS240E.

Moving further along the data flow, a 1783-BMS10CGN Stratix 5700 Managed Switch routes EtherNet/IP traffic between the CompactLogix controller, the remote I/O network, and the plant-floor 2711P-T10C21D8S PanelView Plus 7 HMI. The HMI provides operators with real-time visualization of process variables, alarm states, and trend data — all of which depend on the uninterrupted 24VDC supply that the 1606-XLS240E delivers. Simultaneously, a 1769-SM2 Serial/DeviceNet Communication Module bridges legacy serial devices into the EtherNet/IP backbone, ensuring that older field instruments remain visible to the SCADA system without requiring costly hardware replacement.

At the drive level, a PowerFlex 525 AC Drive receives speed and torque commands from the CompactLogix PLC over EtherNet/IP, while its 24VDC control circuit — powered by the 1606-XLS240E — maintains the drive’s communication card, safety relay, and digital I/O in a continuously ready state. In parallel, a 1769-L16ER-BB1B CompactLogix 5370 controller manages a secondary process cell, with its I/O bus and communication modules all drawing from the same reliable power rail. For remote diagnostics and predictive maintenance, an edge gateway device aggregates data from multiple PLCs and transmits it to a cloud-based MES platform, with the 1606-XLS240E’s DC OK signal providing a hardware-level health indicator that can trigger alarms in the SCADA system if power anomalies are detected.

Solving Data Isolation in Industrial Sites

One of the most persistent challenges in industrial automation is the fragmentation of data across incompatible protocols, isolated control islands, and legacy equipment that was never designed for network connectivity. The Allen-Bradley 1606-XLS240E directly addresses this challenge by providing the stable, high-quality power infrastructure that makes protocol conversion and network integration possible.

When a plant deploys a 1788-EN2DN EtherNet/IP-to-DeviceNet Linking Device to bridge a legacy DeviceNet sensor network into a modern EtherNet/IP backbone, the reliability of that gateway depends entirely on the quality of its 24VDC supply. Voltage fluctuations or power interruptions at the gateway level can corrupt protocol translation buffers, cause communication timeouts, and create the very data isolation that the integration was designed to eliminate. The 1606-XLS240E’s tight output regulation and low ripple ensure that protocol conversion gateways, communication bridges, and network infrastructure devices operate within their specified voltage windows at all times.

For plants seeking to achieve production line transparency — real-time OEE monitoring, automated quality data collection, and remote diagnostics accessible from any location — the 1606-XLS240E provides the power foundation that makes these capabilities reliable rather than intermittent. Its parallel redundancy support allows two units to share load and provide automatic failover, eliminating the single point of failure that would otherwise make remote monitoring systems unreliable. The built-in DC OK output enables integration with the plant’s alarm management system, so maintenance teams receive immediate notification of any power anomaly before it escalates into a network outage or production stoppage.

System expansion is equally straightforward: as new production cells, robotic work stations, or quality inspection stations are added to the network, additional 1606-XLS240E units can be installed in parallel to scale power capacity without redesigning the existing power distribution architecture. This modularity aligns with the phased deployment strategies common in smart factory upgrade projects, where new automation islands must be integrated into the existing SCADA and MES infrastructure with minimal disruption to ongoing production.

Industrial Connectivity FAQ

Q1: Does the 1606-XLS240E support redundant power configurations for high-availability network infrastructure?
Yes. The 1606-XLS240E supports parallel operation for both load sharing and redundancy. Two or more units can be connected in parallel using the optional 1606-XLS redundancy module, providing automatic failover with no interruption to connected network devices, PLCs, or communication gateways. This configuration is recommended for SCADA servers, managed switches, and any network node where downtime is not acceptable.

Q2: Is the 1606-XLS240E compatible with EtherNet/IP, PROFINET, and Modbus TCP network architectures?
The 1606-XLS240E is a DC power supply, not a communication device itself — but it is specifically designed to power the full range of industrial communication hardware used in EtherNet/IP, PROFINET, Modbus TCP, DeviceNet, and ControlNet networks. Its 24VDC output meets the power requirements of Rockwell Automation, Siemens, Schneider Electric, Omron, and Beckhoff communication modules, I/O adapters, and network switches.

Q3: How does the 1606-XLS240E contribute to remote diagnostics and predictive maintenance programs?
The 1606-XLS240E includes a DC OK signal output that provides a hardware-level power health indicator. This signal can be wired to a PLC digital input or a building management system to trigger alarms in the SCADA or HMI if the power supply output falls outside specification. Combined with the unit’s wide operating temperature range and high MTBF rating, this feature supports predictive maintenance strategies by providing early warning of potential power infrastructure issues before they cause network or production failures.

Q4: What quality assurance and warranty coverage does ZYPLC provide for the 1606-XLS240E?
Every 1606-XLS240E supplied by ZYPLC undergoes pre-shipment functional testing to verify output voltage, load regulation, and DC OK signal operation. All units are covered by a 12-month warranty from the date of shipment. ZYPLC maintains in-stock inventory of the 1606-XLS240E and related XLS Series components to support urgent project timelines and emergency replacement requirements. For pricing, availability, and technical support, contact the ZYPLC team directly.

—
