Bosch Rexroth CMP60.1-SP-304-FN-NNNN-NW Servo Drive for IndraDrive

Bosch Rexroth CMP60.1-SP-304-FN-NNNN-NW Servo Drive for IndraDrive

The Bosch Rexroth CMP60.1-SP-304-FN-NNNN-NW is a high-performance servo drive module engineered for seamless system integration within the IndraDrive modular drive architecture. Rather than functioning as a standalone unit, this module is designed to operate as a coordinated node within a layered automation system — interfacing with control, I/O, power, communication, and HMI layers to deliver consistent motion performance, system-wide redundancy, and long-term maintainability across demanding industrial environments.

In modern industrial control architectures, the servo drive layer is not isolated. The CMP60.1-SP-304-FN-NNNN-NW connects upstream to the control layer — typically a Bosch Rexroth IndraControl L or IndraControl XM series PLC — receiving motion commands via SERCOS III or PROFINET real-time communication protocols. Downstream, it interfaces with servo motors such as the MSK series or MKD series synchronous servo motors, translating digital control signals into precise torque, velocity, and position outputs. This tight integration between the controller, drive, and motor ensures deterministic motion response, which is critical in high-speed packaging lines, precision machining centers, and multi-axis coordinated motion systems.

At the power layer, the CMP60.1-SP-304-FN-NNNN-NW operates in conjunction with IndraDrive supply units such as the HMV01 or HCS03 regenerative power supply modules. These supply units provide the DC bus voltage that feeds the drive, while also enabling energy recovery during deceleration phases — reducing overall energy consumption and heat generation within the control cabinet. The coordinated power architecture ensures that voltage fluctuations on the DC bus do not propagate as motion disturbances, maintaining servo loop stability even under dynamic load conditions.

Within the I/O layer, the drive module supports digital and analog I/O expansion through IndraDrive-compatible I/O extension modules, enabling local feedback integration from encoders, resolvers, and external sensors without routing all signals back to the central PLC. This distributed I/O approach reduces wiring complexity, shortens signal latency, and improves fault isolation — particularly important in large-scale systems where cable runs between the control cabinet and field devices can introduce noise and delay.

The communication layer of the CMP60.1-SP-304-FN-NNNN-NW supports SERCOS III as its primary real-time fieldbus, providing isochronous data exchange with cycle times as low as 62.5 µs. This enables the drive to participate in synchronized multi-axis motion profiles managed by the IndraMotion MLC motion logic controller, which coordinates axis interpolation, cam profiles, and electronic gearing across multiple CMP-series drives simultaneously. For facilities using PROFINET-based plant networks, the drive’s dual-port Ethernet interface allows transparent integration into the plant-level communication backbone without requiring additional gateways.

From a redundancy and system resilience perspective, the CMP60.1-SP-304-FN-NNNN-NW supports safe torque off (STO) and safe stop 1 (SS1) safety functions in accordance with IEC 62061 and ISO 13849, enabling integration with safety PLCs and emergency stop circuits without external contactors. When paired with IndraDrive redundant power supply configurations and UPS modules, the drive architecture can maintain controlled deceleration and safe state transitions during power interruptions — a critical requirement in continuous process industries such as petrochemical, water treatment, and metal processing.

For HMI and supervisory integration, the drive’s diagnostic data — including actual current, velocity feedback, temperature, and fault codes — is accessible via the IndraWorks engineering software suite and can be mapped to OPC UA data objects for integration with SCADA systems, MES platforms, or cloud-based condition monitoring solutions. This transparency across the HMI layer enables maintenance engineers to perform predictive diagnostics, trend analysis, and remote parameter adjustment without physical access to the control cabinet.

Engineering teams working with the CMP60.1-SP-304-FN-NNNN-NW benefit from its compatibility with the IndraDrive Cs, IndraDrive Mi, and IndraDrive M platform families, allowing mixed-drive architectures within a single control system. This cross-platform compatibility simplifies spare parts management, reduces training overhead, and enables phased system upgrades without full architecture replacement. The module’s parameter set is fully transferable via the IndraDrive parameter memory card, reducing commissioning time during replacement and ensuring configuration consistency across identical drive axes.

All units supplied by ZYPLC are fully tested, inspected, and covered by a warranty terms confirmed during quotation, with availability subject to RFQ confirmation for shipment arranged after confirmation. Our engineering support team provides pre-sales compatibility verification, commissioning guidance, and post-sales technical assistance to ensure the CMP60.1-SP-304-FN-NNNN-NW integrates correctly into your specific control architecture.

Product Specification Table

System Compatibility Notes

The CMP60.1-SP-304-FN-NNNN-NW achieves its full performance potential when deployed within a coordinated IndraDrive system architecture. At the control layer, the IndraControl XM22 or IndraControl L45 PLC manages motion logic and process sequencing, issuing real-time commands to the drive via SERCOS III. The IndraMotion MLC motion logic controller handles multi-axis interpolation, coordinating the CMP60.1 with adjacent axes running on HCS03 or HMS01 drive modules within the same DC bus segment.

Power distribution is managed by the HMV01.1E regenerative supply unit, which feeds the shared DC bus and recovers braking energy from decelerating axes. Cabinet-level power conditioning is supported by NFD03 mains filters and HNL01 line reactors, which suppress conducted EMI and protect the drive’s input rectifier stage. For safety circuit integration, the MSM safety module or an external safety PLC interfaces with the drive’s STO input, enabling category 3 / PLd safe stop without main contactor interruption.

At the I/O layer, Rexroth Inline I/O or IndraControl S20 distributed I/O modules collect field signals — limit switches, encoder feedback, temperature sensors — and relay them to the control layer via PROFINET, reducing point-to-point wiring to the central cabinet. The MSK050 or MKD071 servo motors connect directly to the CMP60.1’s motor output terminals, with motor feedback routed through the drive’s integrated encoder evaluation circuit. HMI visibility is provided by the IndraControl VCP20 operator panel or a SCADA system connected via OPC UA, giving operators real-time access to drive diagnostics, axis status, and alarm history.

Industrial Application Notes

The CMP60.1-SP-304-FN-NNNN-NW is deployed across a wide range of industrial sectors where precise, coordinated motion control is essential to process integrity and production efficiency.

In automotive and general manufacturing, the module drives servo axes on assembly robots, press feeders, and transfer lines, where synchronized multi-axis motion and rapid cycle times are required. Its SERCOS III interface ensures deterministic axis coordination with sub-millisecond jitter, supporting high-throughput production without positional drift between axes.

In power generation and electrical utilities, the drive is used in turbine governor test rigs, valve actuator control systems, and generator excitation test benches, where stable torque control and safe state management under fault conditions are mandatory. The integrated STO function eliminates the need for external motor contactors in many safety circuit designs, simplifying cabinet layout and reducing maintenance points.

In petrochemical and process industries, the CMP60.1 controls compressor inlet guide vane actuators, pump speed regulation systems, and agitator drives, where continuous operation, thermal stability, and remote diagnostics via SCADA integration are critical. The drive’s OPC UA data exposure enables integration with DCS platforms such as ABB System 800xA or Siemens PCS 7 for unified process visibility.

In water and wastewater treatment, the module manages variable-speed pump drives and aeration blower controls, where energy efficiency, soft-start capability, and remote monitoring reduce operational costs and extend equipment service life. In mining and metallurgy, the drive is applied to conveyor positioning systems, rolling mill tension control, and hoist drive systems, where high continuous current ratings and robust fault recovery are essential for uninterrupted production.

Product Compatibility FAQ

Q1: Is the CMP60.1-SP-304-FN-NNNN-NW compatible with existing IndraDrive M and IndraDrive Cs installations?
Yes. The CMP60.1 series is designed for cross-platform compatibility within the Bosch Rexroth IndraDrive ecosystem. It shares the same DC bus architecture, SERCOS III communication protocol, and IndraWorks parameter management as IndraDrive M (HMD, HDD) and IndraDrive Cs (HCS) series modules. Parameter files created in IndraWorks DS can be transferred directly to the replacement module via the parameter memory card, minimizing commissioning time and ensuring configuration consistency. Always verify firmware version compatibility before deployment in mixed-generation architectures.

Q2: What are the installation and commissioning requirements for integrating this module into an existing control cabinet?
The CMP60.1-SP-304-FN-NNNN-NW requires mounting on a standard IndraDrive system rail within a control cabinet maintaining IP20 internal conditions and an ambient operating temperature between 0°C and 40°C. DC bus connection must be made to a compatible HMV01 or HCS03 supply unit with adequate power rating for the combined axis load. SERCOS III fiber optic or Ethernet ring topology must be configured in IndraWorks prior to drive parameterization. Safety wiring for STO inputs must comply with IEC 62061 Category 3 / PLd requirements. ZYPLC provides pre-sales engineering consultation to verify cabinet layout, bus loading, and safety circuit design before shipment.

Q3: What does the warranty terms confirmed during quotation cover, and what support is available for long-term maintenance?
All CMP60.1-SP-304-FN-NNNN-NW units supplied by ZYPLC are covered by a warranty terms confirmed during quotation against manufacturing defects and functional failures under normal operating conditions. The warranty covers full unit replacement or repair at no additional cost. For long-term maintenance, ZYPLC supports RFQ sourcing for CMP-series modules and compatible IndraDrive components to support rapid replacement in the event of field failures. Our technical team provides remote diagnostic support, firmware update guidance, and parameter backup services to minimize unplanned downtime. Contact us at plc.sales@zyplc.com or +86 19859288691 for maintenance planning and spare parts consultation.
