GE IC695ETM001-HT Ethernet Module for RX3i Automation
The GE IC695ETM001-HT is a high-performance Ethernet Interface Module engineered for the PACSystems RX3i platform, delivering deterministic, low-latency network communication that directly supports energy-efficient factory automation. In modern industrial environments where every millisecond of cycle time and every watt of consumed power matters, the IC695ETM001-HT serves as the communication backbone that enables real-time data exchange between controllers, drives, monitoring systems, and supervisory software — eliminating polling delays that waste CPU cycles and inflate energy overhead.
Designed for demanding industrial environments, the HT (High Temperature) variant of the IC695ETM001-HT extends operational reliability across wider thermal ranges, making it suitable for foundries, press shops, chemical processing lines, and other high-ambient-temperature facilities where standard modules would throttle or fail. Its robust design ensures continuous uptime, reducing unplanned downtime events that not only disrupt production schedules but also generate significant unplanned downtime through cold-start cycles and re-initialization sequences.
Product Specification Table
| Parameter |
Specification |
| SKU |
IC695ETM001-HT |
| Brand / Series |
GE Fanuc / PACSystems RX3i |
| Module Type |
Ethernet Interface Module |
| Communication Protocol |
SRTP, Modbus TCP, EtherNet/IP |
| Network Speed |
10/100 Mbps Auto-Negotiation |
| Power Consumption |
≤ 3.5 W (typical operating) |
| Operating Temperature |
0°C to 60°C (HT variant extended range) |
| Compatible Systems |
PACSystems RX3i Backplane (IC695CHS016, IC695CHS012) |
| Application Environment |
Discrete manufacturing, process control, condition monitoring, motion coordination |
| Energy Saving Value |
Reduces CPU polling overhead; enables demand-response integration via real-time data |
| Warranty |
warranty terms confirmed during quotation |
| Stock Status |
RFQ Available — Ships after outgoing test |
System Compatibility and Application
The IC695ETM001-HT does not operate in isolation — its true maintenance planning value emerges when it is integrated into a well-architected PACSystems RX3i control platform. At the controller level, the IC695CPE305 and IC695CPE310 CPU modules leverage the Ethernet interface to execute high-speed scan cycles with minimal idle-state energy draw, coordinating logic execution with real-time field data rather than relying on fixed-interval polling that wastes processing power.
On the power supply side, the IC695PSD040 40W power supply module provides regulated, efficient DC power to the RX3i backplane, and when paired with the IC695ETM001-HT’s low 3.5W consumption profile, the overall rack power budget remains lean — critical in multi-rack installations where cumulative power draw directly impacts facility energy costs. For applications requiring analog energy data acquisition, the IC695ALG600 analog input module captures voltage, current, and power factor signals from field sensors, feeding that data through the Ethernet module to SCADA or maintenance planning systems for real-time consumption analysis.
Variable frequency drives (VFDs) connected via Modbus TCP or EtherNet/IP — such as those in GE’s AF-650GP drive series — receive speed reference commands and return actual torque and power feedback through the IC695ETM001-HT, enabling closed-loop motor maintenance planning without additional dedicated communication hardware. The IC695CMM004 communications module can complement the Ethernet interface in installations requiring simultaneous serial and network connectivity, ensuring legacy field devices remain integrated without disrupting the condition monitoring data flow.
For distributed I/O architectures, the IC695ETM001-HT supports remote I/O drops using compatible RX3i I/O modules such as the IC695MDL654 discrete output module and IC695MDL664 discrete input module, reducing the need for long home-run wiring runs that introduce resistive losses. HMI panels running Proficy iFIX or Cimplicity connected over Ethernet receive live production and energy KPIs, enabling operators to make informed decisions about load scheduling and equipment sequencing to flatten peak demand curves.
Maintenance and Replacement Notes
In a typical automotive body-in-white welding line, the IC695ETM001-HT enables the PACSystems RX3i controller to synchronize robot controllers, servo drives, and weld timers over a single Ethernet backbone. By replacing legacy serial communication with high-speed Ethernet, inter-device handshake times drop from tens of milliseconds to under one millisecond, allowing the line’s cycle time to be compressed without increasing motor speeds — a direct energy saving achieved through communication efficiency rather than hardware upgrades.
In food and beverage processing, where conveyors, mixers, and packaging machines run continuously across three shifts, the IC695ETM001-HT’s reliable network connectivity allows the RX3i controller to implement demand-based speed control. Rather than running all motors at fixed rated speed, the controller receives real-time throughput data from upstream sensors and adjusts drive references dynamically, reducing average motor loading by 15–25% during non-peak production windows. This translates directly to measurable reductions in monthly electricity consumption without any sacrifice in output quality or line throughput.
Predictive maintenance integration is another key maintenance planning pathway. By streaming vibration, temperature, and current draw data from field sensors through the IC695ETM001-HT to a cloud-connected analytics platform, maintenance teams can identify motors operating outside their efficiency curve weeks before failure. Replacing a degraded motor bearing before it causes a catastrophic failure eliminates the unplanned downtime associated with motors drawing Actual operating results depend on the installed system, load profile, and commissioning parameters.
Every unit of IC695ETM001-HT shipped from ZYPLC undergoes a full functional outgoing test, verifying Ethernet link establishment, SRTP communication handshake, and module self-diagnostics before dispatch. This ensures that the module arrives ready for immediate installation, eliminating commissioning delays that extend the period during which production lines run in degraded or manual mode — both of which are inherently less energy-efficient than fully automated operation.
