Mitsubishi FX2N-48ER Relay Output Module for FX2N

Mitsubishi FX2N-48ER Relay Output Module for FX2N

The Mitsubishi FX2N-48ER is a relay output expansion module purpose-built for integration within the FX2N series programmable logic controller architecture. Designed to extend the discrete output capacity of an FX2N host CPU, this module occupies a critical position in the I/O layer of layered automation systems, enabling engineers to scale control point density without redesigning the control cabinet or replacing the core CPU platform. With 48 relay output points, the FX2N-48ER delivers the output density required for mid-to-large machine control applications while maintaining full electrical and logical compatibility with the FX2N control bus.

In a complete FX2N-based control system, the FX2N-48ER does not operate in isolation. It functions as a downstream I/O extension connected to the FX2N main unit — such as the FX2N-128MR or FX2N-80MR — via the FX2N expansion bus. The host CPU manages program execution, scan cycle timing, and communication arbitration, while the FX2N-48ER handles the physical switching of field devices including solenoid valves, motor contactors, indicator lamps, and relay-driven actuators. This division of responsibility between the CPU layer and the I/O layer is fundamental to scalable, maintainable industrial control design.

System architects integrating the FX2N-48ER into a broader automation platform will typically pair it with complementary modules to achieve full-spectrum control coverage. Analog signal conditioning is handled by modules such as the FX2N-2AD (2-channel analog input) and FX2N-4DA (4-channel analog output), which interface with process transmitters and variable-speed drives. For applications requiring CC-Link fieldbus connectivity, the FX2N-32CCL communication module bridges the FX2N platform to distributed I/O nodes and remote device stations, extending the system’s physical reach without increasing cabinet wiring complexity. The FX2N-CNV-BD interface board enables BD-series communication adapters — including RS-232C and RS-485 options — to be mounted directly on the FX2N CPU, supporting HMI connectivity and SCADA integration.

At the human-machine interface layer, GOT1000 or GOT2000 series panels from Mitsubishi Electric communicate with the FX2N CPU via RS-422 or Ethernet gateways, providing operators with real-time process visualization, alarm management, and parameter adjustment. The FX2N-48ER’s output status is reflected in the CPU’s Y-register map, making all 48 output points directly addressable and monitorable from the HMI without additional configuration. This system integration between the I/O expansion layer and the HMI layer is essential for transparent system diagnostics and rapid fault isolation during production.

Power architecture is equally important in FX2N system design. The FX2N-48ER draws its logic power from the FX2N expansion bus, while the relay output commons are connected to the field power supply — typically 24VDC or 100–240VAC depending on the load type. Engineers must account for the total I/O power budget when combining the FX2N-48ER with other expansion modules such as the FX2N-32ER (32-point relay output) or FX2N-48ET (48-point transistor output), ensuring that the host CPU’s expansion bus current capacity is not exceeded. Proper power segmentation between the control circuit and the field circuit is a standard requirement in IEC 60204-compliant machine installations.

For redundancy-sensitive applications, the FX2N-48ER can be deployed in architectures where the FX2N CPU is backed by an uninterruptible power supply and the output relay contacts are wired through safety relays or hardwired interlock circuits. While the FX2N platform does not natively support hot-standby CPU redundancy, system-level redundancy can be achieved through careful I/O segmentation, watchdog timer configuration, and the use of external safety relay modules in the output circuit. This approach is common in water treatment, packaging, and light manufacturing applications where process continuity is required but full safety PLC certification is not mandated.

Long-term maintainability is a core advantage of the FX2N-48ER within established FX2N installations. Because the module uses standard relay output technology, field technicians can verify output status with a basic multimeter without specialized diagnostic tools. Relay contact life ratings and coil drive specifications are well-documented, and replacement modules are available through authorized Mitsubishi Electric distributors and specialist industrial component suppliers. Stocking a spare FX2N-48ER alongside the host CPU and power supply module is a recommended practice for facilities operating continuous production lines where unplanned downtime carries significant cost.

All FX2N-48ER units supplied by ZYPLC are covered by a warranty terms confirmed during quotation and undergo functional verification prior to dispatch. Each unit is tested for relay contact continuity, bus communication integrity, and LED indicator operation. This pre-shipment verification process ensures that replacement and new-installation units arrive ready for immediate commissioning, reducing engineering time on-site and supporting the system integration requirements of complex multi-module FX2N architectures.

Product Specification Table

System Compatibility Notes

A well-engineered FX2N control system integrates the FX2N-48ER as part of a coordinated multi-module architecture. The FX2N-128MR or FX2N-80MR serves as the host CPU, providing the program scan engine and the expansion bus master. The FX2N-48ER connects directly to the right side of the CPU or to a preceding expansion module, extending the output register map seamlessly. For mixed I/O requirements, the FX2N-32ER (32-point relay output) or FX2N-48ET (48-point transistor output, suitable for high-frequency switching and NPN/PNP load compatibility) may be combined with the FX2N-48ER in the same expansion chain to address different load types within a single cabinet.

Analog process variables are managed by the FX2N-2AD and FX2N-4DA modules, which handle 4–20mA and 0–10V signals from field transmitters and feed setpoints to variable-frequency drives. Network connectivity is extended via the FX2N-32CCL CC-Link master module, which allows the FX2N CPU to communicate with remote I/O stations, inverter drives, and smart sensors distributed across the plant floor. The FX2N-CNV-BD interface board, combined with an FX2N-485-BD or FX2N-232-BD adapter, enables RS-485 Modbus RTU communication to SCADA systems or third-party HMI panels. Terminal block modules such as the A6TBXY36 provide organized field wiring termination for the relay outputs, reducing installation time and improving long-term maintainability in high-density wiring environments.

Industrial Application Notes

The FX2N-48ER is deployed across a wide range of industrial sectors where relay output density and FX2N platform compatibility are primary selection criteria. In manufacturing and assembly lines, the module controls pneumatic solenoid valves, conveyor motor starters, and part-present indicator lamps, with the FX2N CPU coordinating sequence logic across multiple expansion modules. In water treatment and pumping stations, the relay outputs drive pump motor contactors, valve actuators, and alarm annunciators, with the system communicating process data to a SCADA host via the FX2N-485-BD adapter. In power distribution and substation automation, the FX2N-48ER provides switching outputs for protection relay trip circuits and status indication panels, where relay contact isolation between the control circuit and the high-voltage field circuit is a mandatory design requirement.

In petrochemical and process industries, the module is used in conjunction with analog I/O modules to implement basic regulatory control loops, with relay outputs managing on/off control of process valves and pump drives. In packaging and material handling, high output point counts are essential for controlling multiple actuators simultaneously, and the FX2N-48ER’s 48-point capacity reduces the number of expansion modules required, simplifying cabinet layout and reducing bus loading on the FX2N CPU. In mining and metallurgy, the module’s robust relay contact ratings support the switching of heavy inductive loads in harsh electrical environments, where transistor output modules would require additional surge suppression circuitry.

Product Compatibility FAQ

Q1: How many FX2N-48ER modules can be connected to a single FX2N CPU, and what are the expansion bus constraints?
The FX2N CPU supports a maximum of 8 expansion modules in a single expansion chain, with a total I/O point limit of 256 points (including the CPU’s built-in I/O). The expansion bus current capacity must also be observed — each FX2N-48ER draws logic current from the bus, and the total current consumption of all connected expansion modules must not exceed the CPU’s rated expansion bus output current. Engineers should calculate the total bus current load during system design and, if necessary, use an FX2N-CNV-IF interface module to connect a second expansion chain with its own power supply.

Q2: Is the FX2N-48ER compatible with FX2NC or FX3U series CPUs, and what adapters are required?
The FX2N-48ER is designed for the FX2N expansion bus and is not directly compatible with FX2NC or FX3U CPUs without an interface adapter. The FX2NC series uses a compact connector format, and an FX2NC-CNV-IF adapter is required to connect FX2N-series expansion modules. For FX3U systems, Mitsubishi Electric recommends using FX3U-series native expansion modules for full compatibility and support. If an FX2N-48ER must be integrated into an FX3U system for legacy reasons, consult the FX3U hardware manual for adapter requirements and verify bus current compatibility before installation.

Q3: What does the warranty terms confirmed during quotation cover, and how does ZYPLC support long-term maintenance and spare parts availability?
The warranty terms confirmed during quotation provided by ZYPLC covers manufacturing defects and functional failures under normal operating conditions for a period of 12 months from the date of shipment. Units that fail within the warranty period are repaired or replaced at no charge, subject to inspection confirming that the failure is not attributable to misapplication, overvoltage, or physical damage. For long-term maintenance planning, ZYPLC supports RFQ sourcing for FX2N-series modules including the FX2N-48ER, FX2N-80MR, FX2N-32ER, and related expansion components, supporting facilities that require rapid replacement of failed modules to minimize production downtime. Contact the ZYPLC technical team for spare parts availability, lead times, and volume pricing for maintenance stock programs.
