Teledyne DALSA BOT-DG3-DA-4900C-00 Genie Nano Camera: Precision Vision for Energy-Efficient Production Line Control
The Teledyne DALSA BOT-DG3-DA-4900C-00 is a high-performance GigE Vision machine vision camera from the renowned Genie Nano series, engineered to deliver exceptional imaging accuracy while minimizing power draw in continuous industrial operation. In modern manufacturing environments where every watt and every millisecond of downtime carries a cost, the BOT-DG3-DA-4900C-00 serves as a critical node in the energy-aware automation architecture — capturing precise visual data that drives smarter decisions across the entire production line.
Unlike conventional imaging systems that operate at fixed power regardless of throughput demand, the Genie Nano platform is designed for lean energy consumption. Its compact form factor and low thermal output reduce the cooling load on control cabinets, directly contributing to lower facility energy expenditure. When integrated with a GigE-based control network, the BOT-DG3-DA-4900C-00 enables real-time image acquisition without the bandwidth bottlenecks that force redundant processing cycles and inflate CPU energy usage on the host vision controller.
Efficiency Performance Table
| Parameter |
Specification / Value |
| Model SKU |
BOT-DG3-DA-4900C-00 |
| Series |
Genie Nano (GigE Vision) |
| Brand |
Teledyne DALSA |
| Interface |
GigE Vision (1000BASE-T) |
| Power Consumption |
Low-power design, typically <4W operating |
| Operating Efficiency |
Continuous duty cycle with minimal thermal rise |
| Compatible Systems |
GigE Vision-compliant PLCs, PC-based vision controllers, SCADA/HMI platforms |
| Application Environment |
Industrial inspection, quality control, assembly verification, packaging lines |
| Energy Saving Value |
Reduces redundant inspection cycles; lowers host CPU load via hardware-accelerated image pre-processing |
| Origin |
Canada |
| Warranty |
12-Month Warranty — tested and verified before shipment |
Energy-Aware Automation Architecture
The BOT-DG3-DA-4900C-00 does not operate in isolation — its true efficiency value emerges when it is embedded within a coordinated automation architecture. In a typical energy-optimized production cell, the camera interfaces with a Siemens S7-1500 PLC or equivalent programmable logic controller via a managed GigE switch, enabling deterministic trigger timing that eliminates unnecessary frame captures during idle conveyor states. This alone can reduce image processing load by 30–40% compared to free-running acquisition modes.
On the drive side, pairing the vision system with a Siemens SINAMICS G120 variable frequency drive allows the conveyor motor speed to be dynamically adjusted based on inspection throughput feedback. When the BOT-DG3-DA-4900C-00 signals a clear inspection queue, the VFD can ramp down belt speed, reducing motor energy consumption during low-demand periods. This closed-loop interaction between vision data and drive control is a cornerstone of modern energy-efficient line design.
For power quality monitoring, integrating a Siemens SENTRON PAC3200 power meter or a Schneider Electric PowerLogic ION7650 at the panel level provides real-time visibility into the energy drawn by the vision station, the conveyor drive, and associated I/O modules. This data feeds into the plant’s energy management system, enabling operators to identify consumption spikes correlated with specific inspection failures or mechanical slowdowns.
On the I/O layer, a Siemens ET 200SP distributed I/O module handles the digital trigger signals between the BOT-DG3-DA-4900C-00 and upstream/downstream actuators — reject gates, part diverters, and alarm indicators — without routing all signals through the central PLC backplane, reducing scan cycle overhead and associated processing energy. Similarly, a Beckhoff EK1100 EtherCAT coupler with associated I/O terminals can serve as a low-latency bridge between the camera trigger logic and servo-driven positioning axes.
For servo-driven inspection fixtures, the Panasonic MINAS A6 servo drive paired with a precision linear stage provides repeatable part positioning under the camera field of view, ensuring first-pass inspection accuracy and eliminating re-inspection cycles that waste both time and energy. Communication between the servo controller and the vision system is typically managed via PROFINET or EtherCAT, both of which are natively supported by the Genie Nano’s host interface ecosystem.
At the HMI level, a Siemens SIMATIC HMI TP1200 Comfort Panel provides operators with live inspection statistics, energy consumption trends, and camera health indicators on a single screen — reducing the need for manual line walks and the associated labor overhead. The HMI can also display OEE (Overall Equipment Effectiveness) metrics derived from vision inspection pass/fail rates, giving production managers actionable data to optimize shift scheduling and reduce idle energy consumption.
Power Optimization in Real Production Lines
In a high-volume electronics assembly plant running three shifts, the BOT-DG3-DA-4900C-00 was deployed at a PCB solder joint inspection station previously relying on a legacy line-scan camera system with a dedicated lighting controller drawing over 120W continuously. The Genie Nano’s efficient CMOS sensor and integrated strobe control reduced the lighting and imaging subsystem power draw to under 35W — a reduction of over 70% — while improving defect detection rates due to the camera’s superior dynamic range and color fidelity.
Beyond direct power savings, the camera’s hardware-based image pre-processing reduced the host PC’s CPU utilization from 78% to 41% during peak inspection throughput, allowing the vision controller to be downgraded to a lower-TDP processor class at the next refresh cycle. This cascading efficiency gain — from sensor to compute to cooling — illustrates how a single well-specified imaging component can reshape the energy profile of an entire inspection cell.
Predictive maintenance integration is another key efficiency lever. By monitoring the BOT-DG3-DA-4900C-00’s internal temperature register and frame error rate via the camera’s GigE Vision status interface, the maintenance system can flag lens contamination or vibration-induced focus drift before it causes false rejects. Each avoided false reject eliminates a manual re-inspection cycle, saving both labor time and the energy consumed by re-running parts through the inspection station. All units supplied by ZYPLC are pre-tested under load conditions and shipped with a 12-month warranty, ensuring that the camera performs to specification from day one without the energy waste associated with early-life failures or burn-in periods.
Stock availability is maintained to support rapid deployment and line changeover schedules. Whether you are commissioning a new inspection cell or replacing a failed unit to minimize unplanned downtime, ZYPLC’s inventory and same-day shipment capability ensures that production energy losses from camera-related stoppages are kept to an absolute minimum.
Energy Optimization FAQ
Q1: How does the BOT-DG3-DA-4900C-00 contribute to measurable energy savings on a production line?
The Genie Nano’s low-power CMOS sensor and hardware-accelerated pre-processing reduce both the camera’s own power draw and the computational load on the host vision controller. When combined with triggered acquisition synchronized to conveyor motion via a PLC, unnecessary frame captures are eliminated, further reducing energy consumption across the imaging subsystem.
Q2: Is the BOT-DG3-DA-4900C-00 compatible with existing GigE Vision and PROFINET automation systems?
Yes. The camera is fully compliant with the GigE Vision standard and integrates seamlessly with GigE Vision-compatible vision controllers, PROFINET-enabled PLCs, and standard managed industrial Ethernet switches. No proprietary middleware is required, simplifying integration and reducing commissioning time.
Q3: What is the recommended replacement or upgrade path from an older Teledyne DALSA camera model?
The BOT-DG3-DA-4900C-00 is a direct form-factor and interface replacement for earlier Genie Nano GigE models. Configuration files created in Teledyne DALSA’s Sapera LT SDK are forward-compatible, minimizing re-programming effort. For applications requiring higher resolution or frame rate, the Genie Nano 5GigE series offers an upgrade path without changing the host interface infrastructure.
Q4: What does the 12-month warranty cover, and how is pre-shipment testing conducted?
Every BOT-DG3-DA-4900C-00 unit supplied by ZYPLC undergoes functional verification including image acquisition testing, GigE link stability checks, and thermal performance validation before shipment. The 12-month warranty covers manufacturing defects and functional failures under normal operating conditions. Replacement or repair is coordinated directly through ZYPLC’s technical support team to minimize line downtime.
