Allen-Bradley 1746-OX8 Industrial Network Interface for SLC 500 Systems

Allen-Bradley 1746-OX8 Industrial Network Interface for SLC 500 Systems

The Allen-Bradley 1746-OX8 is an 8-point relay output module engineered for the SLC 500 modular I/O platform, delivering robust discrete control across demanding industrial environments. Designed to bridge field-level devices and upper-level control systems, the 1746-OX8 serves as a critical link in the industrial data chain — connecting PLC logic outputs to actuators, solenoids, motor starters, and signal lamps with reliable relay switching. Whether deployed in automotive assembly, food processing, water treatment, or discrete manufacturing, this module ensures deterministic output response and long-term operational stability in smart factory architectures.

Within a typical SLC 500 control rack, the 1746-OX8 operates alongside the 1746-P4 power supply and communicates through the SLC 500 backplane to the 1747-L553 processor. The processor executes ladder logic and drives relay coil states through the module’s eight isolated output channels, each rated for AC and DC loads. This architecture supports seamless integration with Allen-Bradley’s broader ControlLogix and MicroLogix ecosystems when bridged via the 1747-SDN DeviceNet Scanner or the 1747-KE DH-485 to RS-232 interface module, enabling cross-platform data visibility from field devices up to SCADA and MES layers.

Network Communication Table

Connected Automation Data Flow

In a fully connected smart factory deployment, the 1746-OX8 sits at the output end of a carefully orchestrated data flow that begins at the sensor layer and terminates at enterprise-level reporting systems. Field sensors — including photoelectric sensors, proximity switches, and temperature transmitters — feed analog and digital signals into the SLC 500 rack via companion input modules such as the 1746-IB16 DC input module or the 1746-NI8 analog input module. The 1747-L553 SLC 5/05 processor, equipped with an onboard EtherNet/IP port, processes this incoming data and executes control logic that drives the 1746-OX8 relay outputs to actuate downstream devices.

For facilities requiring protocol conversion between legacy SLC 500 networks and modern Ethernet-based infrastructure, the 1761-NET-ENI Serial-to-EtherNet/IP adapter provides a transparent gateway, allowing SCADA platforms such as Ignition by Inductive Automation or Rockwell’s FactoryTalk View SE to poll real-time I/O status from the 1746-OX8 module. This data path enables operators to monitor relay state, output load current, and fault conditions from centralized HMI panels — including the PanelView Plus 7 — without interrupting field-level control cycles.

Where DeviceNet topology is in use, the 1747-SDN DeviceNet Scanner module installed in the same SLC 500 chassis allows the 1746-OX8’s output states to be coordinated with distributed I/O nodes, variable frequency drives such as the PowerFlex 40, and remote I/O adapters across the plant floor. This multi-node architecture supports real-time alarm feedback, predictive maintenance triggers, and remote diagnostics — all routed through the SLC 500 backplane and upward through the plant’s Ethernet backbone to SCADA dashboards and cloud-based MES platforms.

For edge computing scenarios, an industrial edge gateway — such as the Moxa UC-8112 or Advantech WISE-5000 series — can be configured to subscribe to EtherNet/IP tags from the 1747-L553 processor, aggregating 1746-OX8 output data alongside drive status from PowerFlex 525 VFDs and sensor readings from IO-Link masters. This edge layer enables local analytics, anomaly detection, and OEE calculation before forwarding summarized data to cloud platforms via MQTT or OPC-UA, completing the IIoT data chain from relay contact to enterprise dashboard.

Solving Data Isolation in Industrial Sites

One of the most persistent challenges in legacy industrial environments is protocol fragmentation — where SLC 500 systems running DH-485 or DH+ cannot natively communicate with newer EtherNet/IP-based controllers or cloud-connected SCADA platforms. The 1746-OX8, when deployed within a properly architected SLC 500 rack, becomes the output execution point for a unified control strategy that resolves this isolation. By pairing the module with protocol gateway devices such as the ProSoft Technology MVI46-MCM Modbus Communication Module or the 1747-KE DH-485 to RS-232 interface, engineers can bridge legacy SLC 500 I/O data — including the relay states of the 1746-OX8 — into modern Modbus TCP, EtherNet/IP, or OPC-UA data streams accessible to any SCADA or MES platform.

Production line transparency is achieved when every output action of the 1746-OX8 — whether energizing a conveyor motor starter or triggering a pneumatic valve — is logged with a timestamp and associated process variable in the SCADA historian. This traceability eliminates data silos between the PLC layer and the operations management layer, enabling root-cause analysis of downtime events, cycle time optimization, and compliance reporting without manual data collection. Remote monitoring capabilities further extend this transparency: maintenance engineers can diagnose relay output faults, verify load switching cycles, and initiate controlled shutdowns from off-site locations through secure VPN-connected HMI sessions.

System scalability is a core advantage of the SLC 500 modular architecture. As production demands grow, additional 1746-OX8 modules can be added to expanded chassis configurations — such as the 1746-A13 13-slot chassis — without redesigning the control program. This plug-and-expand approach, combined with the module’s compatibility with the full SLC 500 I/O library, ensures that the 1746-OX8 remains a long-term investment in industrial connectivity infrastructure.

Every 1746-OX8 unit supplied by ZYPLC undergoes pre-shipment functional testing, verifying relay coil actuation, contact continuity, and backplane communication integrity before dispatch. Units are shipped via DHL Express or FedEx International Priority with full tracking, and are backed by a 12-month warranty covering manufacturing defects and operational failures under normal industrial use conditions. In-stock inventory ensures rapid fulfillment for urgent MRO requirements and unplanned downtime scenarios.

Industrial Connectivity FAQ

Q1: What communication protocols does the 1746-OX8 support for SCADA integration?
The 1746-OX8 communicates natively via the SLC 500 backplane I/O bus. For SCADA integration, the 1747-L553 SLC 5/05 processor’s onboard EtherNet/IP port enables direct polling by FactoryTalk View SE, Ignition SCADA, and other EtherNet/IP-compatible platforms. Legacy DH-485 and DH+ networks can be bridged using the 1747-KE or 1761-NET-ENI adapters, ensuring compatibility with both modern and existing SCADA architectures.

Q2: How does the 1746-OX8 perform in high-cycle industrial applications, and what is the relay life expectancy?
The 1746-OX8 relay contacts are rated for a minimum of 100,000 mechanical operations and 100,000 electrical operations at rated load. For high-frequency switching applications, it is recommended to evaluate load type (resistive vs. inductive) and apply appropriate surge suppression to extend contact life. The module’s isolated relay design prevents cross-channel interference, maintaining output integrity even in electrically noisy industrial environments.

Q3: Can the 1746-OX8 be integrated into a network with newer ControlLogix or CompactLogix systems?
Yes. Using the 1747-SDN DeviceNet Scanner or a ControlLogix-to-SLC 500 gateway bridge, the 1746-OX8’s I/O data can be mapped into a ControlLogix or CompactLogix tag database. This allows unified programming in Studio 5000 Logix Designer while retaining existing SLC 500 field wiring, protecting capital investment during phased system modernization projects.

Q4: What warranty and quality assurance does ZYPLC provide for the 1746-OX8?
All 1746-OX8 units supplied by ZYPLC are covered by a 12-month warranty from the date of shipment. Each unit undergoes pre-shipment functional testing including relay actuation verification, backplane communication check, and contact resistance measurement. Certificates of conformance are available upon request. For urgent requirements, in-stock units can be dispatched within 24 hours via DHL Express or FedEx International Priority with full shipment tracking.

—
