Kollmorgen S71262-NANANA System-Ready Servo Drive for S700 Series Architecture

Kollmorgen S71262-NANANA System-Ready Servo Drive for S700 Series Architecture: Control System Coordination and Upstream-Downstream Synchronization

The Kollmorgen S71262-NANANA is a high-performance servo drive engineered for seamless integration within the S700 Series control architecture. Rather than functioning as a standalone motion component, this drive is designed from the ground up to operate as a coordinated node within a layered industrial automation system — spanning the control layer, I/O layer, network layer, power layer, human-machine interface layer, and execution layer. Its role in the system is to translate digital command signals from the upper control layer into precise, real-time mechanical motion at the execution layer, while maintaining full bidirectional communication with supervisory controllers and diagnostic platforms.

In modern industrial automation environments — whether applied to manufacturing assembly lines, power generation facilities, petrochemical processing plants, water treatment infrastructure, mining operations, metallurgical production, packaging lines, or continuous process control systems — the servo drive is not merely a power conversion device. It is a critical architectural element that determines system responsiveness, positional accuracy, fault tolerance, and long-term maintainability. The S71262-NANANA fulfills this role within the Kollmorgen S700 ecosystem with a level of integration depth that reduces commissioning time, simplifies diagnostics, and supports scalable system expansion.

Architecture Specification Table

Coordinated Control System Design

The S71262-NANANA achieves its full performance potential when deployed as part of a coordinated S700-based control system. At the control layer, it receives motion commands from a Kollmorgen AKD-series master controller or a third-party PLC such as a Siemens S7-300/S7-400 or Allen-Bradley ControlLogix platform via a standardized fieldbus interface. The drive interprets these commands in real time and executes them at the motor shaft with sub-millisecond latency, ensuring that the mechanical execution layer remains tightly synchronized with the supervisory control logic.

At the I/O layer, the S71262-NANANA interfaces with digital and analog I/O modules — such as Kollmorgen S700 expansion I/O cards or third-party I/O terminals — to receive limit switch signals, home position inputs, and external enable/disable commands. This bidirectional I/O integration allows the drive to participate in safety interlocks and sequence logic without requiring additional relay logic or intermediate signal converters.

At the network layer, the drive supports multi-node fieldbus topologies. In a typical S700 architecture, multiple S71262-NANANA drives may be daisy-chained on a single CANopen or EtherCAT segment, with each node addressed independently by the master controller. This topology reduces wiring complexity, supports real-time synchronization across multiple axes, and enables centralized fault monitoring from a single SCADA or HMI terminal.

At the power layer, the S71262-NANANA is designed to operate in conjunction with Kollmorgen S700 series regenerative power supplies and DC bus sharing modules. In multi-axis cabinet designs, shared DC bus architecture allows braking energy from decelerating axes to be redistributed to accelerating axes, reducing net energy consumption and minimizing heat dissipation within the control cabinet. This is particularly relevant in high-cycle applications such as packaging machinery, press lines, and robotic welding cells.

At the human-machine interface layer, the drive integrates with Kollmorgen WorkBench software for parameter configuration, auto-tuning, oscilloscope diagnostics, and firmware management. In larger system architectures, WorkBench can be networked to monitor multiple S700 drives simultaneously, providing maintenance engineers with a unified view of drive health, fault history, and performance trends. This capability significantly reduces mean time to repair (MTTR) in production environments where downtime is costly.

At the execution layer, the S71262-NANANA drives Kollmorgen AKM-series or TBM-series servo motors, providing closed-loop torque, velocity, and position control with high dynamic response. The drive’s Smart Feedback Device (SFD) interface eliminates the need for separate encoder cables on compatible motors, simplifying installation and reducing potential failure points in the feedback signal chain. For legacy motor installations, the drive also supports standard incremental and absolute encoders, as well as resolver feedback, ensuring backward compatibility within mixed-generation system architectures.

In redundant system designs, the S71262-NANANA can be deployed in hot-standby or cold-standby configurations alongside a backup drive unit. The system controller monitors drive health via the fieldbus interface and can initiate automatic failover in the event of a drive fault, maintaining production continuity in critical applications such as power plant auxiliary systems, water treatment pump stations, and continuous chemical process lines.

Application in Layered Automation Systems

Manufacturing and Assembly: In automotive body shop and general manufacturing environments, the S71262-NANANA provides the precise motion control required for robotic arm positioning, conveyor indexing, and press brake actuation. Its fast current loop response and high-resolution feedback processing ensure repeatable positioning accuracy across thousands of production cycles per shift.

Power Generation and Utilities: In power plant auxiliary systems — including boiler feed pump drives, induced draft fan controls, and turbine governor actuators — the S71262-NANANA delivers the torque stability and communication reliability required for continuous, unattended operation. Its compatibility with PROFIBUS-DP and EtherCAT fieldbus protocols allows direct integration with DCS platforms commonly used in power generation facilities.

Petrochemical and Process Industries: In refinery and chemical plant environments, servo drives must operate reliably in the presence of electrical noise, temperature variation, and vibration. The S71262-NANANA’s robust EMC design and cabinet-mount IP20 enclosure make it suitable for installation in well-engineered control rooms adjacent to process areas, where it controls metering pumps, agitator drives, and valve actuators with high precision.

Water and Wastewater Treatment: Municipal water treatment facilities rely on precise flow control for chemical dosing, filtration backwash cycles, and pump station management. The S71262-NANANA supports velocity-controlled pump drives with soft-start and soft-stop profiles, reducing water hammer effects and extending pump mechanical life.

Mining and Metallurgy: In ore processing and metal forming applications, the drive’s high dynamic torque response supports conveyor belt tensioning, crusher feed rate control, and rolling mill speed regulation. Its ability to operate within a shared DC bus architecture is particularly valuable in regenerative applications such as downhill conveyor systems.

Packaging and Material Handling: High-speed packaging lines demand servo drives capable of executing complex motion profiles — including electronic gearing, cam following, and registration correction — with deterministic timing. The S71262-NANANA’s EtherCAT compatibility enables microsecond-level synchronization across multiple axes in multi-station packaging machines.

Architecture Engineering FAQ

Q1: Is the S71262-NANANA compatible with third-party PLCs and DCS platforms, or is it limited to Kollmorgen controllers?
The S71262-NANANA is designed for open-architecture integration. Via its CANopen, EtherCAT, PROFIBUS-DP, and serial communication interfaces, it can be commanded by a wide range of third-party controllers including Siemens S7 series, Rockwell ControlLogix, Schneider Modicon, and Mitsubishi MELSEC platforms. Kollmorgen WorkBench software handles drive-side parameter configuration independently of the upper controller, allowing system integrators to adapt the drive to virtually any supervisory control architecture without modifying the host PLC program structure.

Q2: What commissioning and diagnostic tools are available for the S71262-NANANA in a multi-axis system architecture?
Kollmorgen WorkBench provides the primary commissioning environment for the S71262-NANANA, offering auto-tuning wizards, real-time oscilloscope traces, fault log review, and firmware update management. In networked multi-axis installations, WorkBench can connect to multiple S700 drives simultaneously over the fieldbus or direct USB/RS-232 connection, enabling parallel commissioning and centralized diagnostics. For integration with SCADA systems, drive status and fault data can be mapped to standard fieldbus registers accessible by the supervisory controller.

Q3: What does the 12-Month Warranty cover, and what support is available for long-term maintenance of the S71262-NANANA in critical infrastructure applications?
The 12-Month Warranty provided by ZYPLC covers manufacturing defects, hardware component failures, and firmware integrity issues identified under normal operating conditions. For long-term maintenance planning, ZYPLC maintains verified inventory of S700 series components — including replacement drives, power supply modules, and feedback accessories — to support spare parts programs for critical infrastructure operators. Customers in power generation, water treatment, and process industries are encouraged to establish a minimum one-unit hot-spare inventory policy for each S71262-NANANA installation to ensure rapid replacement capability in the event of an unplanned drive failure. ZYPLC technical support is available to assist with replacement unit configuration, parameter transfer, and recommissioning procedures.
